Overview
- Poly-Flo Dog Bone
- with transition to single tube
- machined
- simultaneous + cascade welding
- PPR grey
| Dimension | Code | Detail | Unit | Weight |
|---|---|---|---|---|
| 50/32 | 11.197.5032.71 | 50/32 SDR17/11 | piece | 0.042 |
| 90/63 | 11.197.9063.71 | 90/63 SDR17/11 | piece | 0.185 |
| 160/110 | 11.197.1611.71 | 160/110 SDR17/11 | piece | 0.785 |
| 225/160 | 11.197.2216.71 | 225/160 SDR17/11 | piece | 1.490 |
