Overview

Dimension	Code	Detail	Unit	Weight
200	12.705.0200.00	200X3,0 Ventilation	metre	1.828
250	12.705.0250.00	250X3,5 Ventilation	metre	2.657
315	12.705.0315.00	315X5,0 Ventilation	metre	4.736
355	12.705.0355.00	355X6,0 Ventilation	metre	6.390
400	12.705.0400.00	400X6,0 Ventilation	metre	7.200
450	12.705.0450.00	450X6,0 Ventilation	metre	8.100
500	12.705.0500.00	500X8,0 Ventilation	metre	11.900
560	12.705.0560.00	560X8,0 Ventilation	metre	13.410
630	12.705.0630.00	630X10,0 Ventilation	metre	18.800
710	12.705.0710.00	710X12,0 Ventilation	metre	25.300
800	12.705.0800.00	800X12,0 Ventilation	metre	28.600
900	12.705.0900.00	900X15,0 Ventilation	metre	40.100
1000	12.705.1000.00	1000X15,0 Ventilation	metre	44.600
1200	12.705.1200.00	1200X18,0 Ventilation	metre	64.100
1400	12.705.1400.00	1400X20,0 Ventilation	metre	83.200
110	12.705.0110.41	110X2,7 SDR41 ISO S-20	metre	0.903
125	12.705.0125.41	125X3,1 SDR41 ISO S-20	metre	1.170
140	12.705.0140.41	140X3,5 SDR41 ISO S-20	metre	1.480
160	12.705.0160.41	160X4,0 SDR41 ISO S-20	metre	1.910
180	12.705.0180.41	180X4,4 SDR41 ISO S-20	metre	2.360
200	12.705.0200.41	200X4,9 SDR41 ISO S-20	metre	2.920
225	12.705.0225.41	225X5,5 SDR41 ISO S-20	metre	3.700
250	12.705.0250.41	250X6,2 SDR41 ISO S-20	metre	4.590
280	12.705.0280.41	280X6,9 SDR41 ISO S-20	metre	5.730
315	12.705.0315.41	315X7,7 SDR41 ISO S-20	metre	7.190
355	12.705.0355.41	355X8,7 SDR41 ISO S-20	metre	9.140
400	12.705.0400.41	400X9,8 SDR41 ISO S-20	metre	11.600
450	12.705.0450.41	450X11,0 SDR41 ISO S-20	metre	14.600
500	12.705.0500.41	500X12,3 SDR41 ISO S-20	metre	18.100
560	12.705.0560.41	560X13,7 SDR41 ISO S-20	metre	22.600
630	12.705.0630.41	630X15,4 SDR41 ISO S-20	metre	28.500
710	12.705.0710.41	710X17,4 SDR41 ISO S-20	metre	36.300
800	12.705.0800.41	800X19,6 SDR41 ISO S-20	metre	46.100
900	12.705.0900.41	900X22,0 SDR41 ISO S-20	metre	58.100
1000	12.705.1000.41	1000X24,5 SDR41 ISO S-20	metre	72.000
1200	12.705.1200.41	1200X29,4 SDR41 ISO S-20	metre	103.000
1400	12.705.1400.41	1400X34,3 SDR41 ISO S-20	metre	141.000
75	12.705.0075.33	75X2,3 SDR33 ISO S-16	metre	0.518
90	12.705.0090.33	90X2,8 SDR33 ISO S-16	metre	0.758
110	12.705.0110.33	110X3,4 SDR33 ISO S-16	metre	1.110
125	12.705.0125.33	125X3,9 SDR33 ISO S-16	metre	1.450
140	12.705.0140.33	140X4,3 SDR33 ISO S-16	metre	1.780
160	12.705.0160.33	160X4,9 SDR33 ISO S-16	metre	2.320
180	12.705.0180.33	180X5,5 SDR33 ISO S-16	metre	2.940
200	12.705.0200.33	200X6,2 SDR33 ISO S-16	metre	3.650
225	12.705.0225.33	225X6,9 SDR33 ISO S-16	metre	4.570
250	12.705.0250.33	250X7,7 SDR33 ISO S-16	metre	5.670
280	12.705.0280.33	280X8,6 SDR33 ISO S-16	metre	7.090
315	12.705.0315.33	315X9,7 SDR33 ISO S-16	metre	8.970
355	12.705.0355.33	355X10,9 SDR33 ISO S-16	metre	11.300
400	12.705.0400.33	400X12,3 SDR33 ISO S-16	metre	14.400
450	12.705.0450.33	450X13,8 SDR33 ISO S-16	metre	18.200
500	12.705.0500.33	500X15,3 SDR33 ISO S-16	metre	22.300
560	12.705.0560.33	560X17,2 SDR33 ISO S-16	metre	28.100
630	12.705.0630.33	630X19,3 SDR33 ISO S-16	metre	35.500
710	12.705.0710.33	710X21,8 SDR33 ISO S-16	metre	45.200
800	12.705.0800.33	800X24,5 SDR33 ISO S-16	metre	57.200
900	12.705.0900.33	900X27,6 SDR33 ISO S-16	metre	72.500
1000	12.705.1000.33	1000X30,6 SDR33 ISO S-16	metre	89.200
1200	12.705.1200.33	1200X36,7 SDR33 ISO S-16	metre	128.000
40	12.705.0040.26	40X1,8 SDR26 ISO S-12,5	metre	0.217
50	12.705.0050.26	50X2,0 SDR26 ISO S-12,5	metre	0.301
63	12.705.0063.26	63X2,5 SDR26 ISO S-12,5	metre	0.474
75	12.705.0075.26	75X2,9 SDR26 ISO S-12,5	metre	0.647
90	12.705.0090.26	90X3,5 SDR26 ISO S-12,5	metre	0.936
110	12.705.0110.26	110X4,2 SDR26 ISO S-12,5	metre	1.360
125	12.705.0125.26	125X4,8 SDR26 ISO S-12,5	metre	1.760
140	12.705.0140.26	140X5,4 SDR26 ISO S-12,5	metre	2.210
160	12.705.0160.26	160X6,2 SDR26 ISO S-12,5	metre	2.890
180	12.705.0180.26	180X6,9 SDR26 ISO S-12,5	metre	3.630
200	12.705.0200.26	200X7,7 SDR26 ISO S-12,5	metre	4.500
225	12.705.0225.26	225X8,6 SDR26 ISO S-12,5	metre	5.650
250	12.705.0250.26	250X9,6 SDR26 ISO S-12,5	metre	6.990
280	12.705.0280.26	280X10,7 SDR26 ISO S-12,5	metre	8.720
315	12.705.0315.26	315X12,1 SDR26 ISO S-12,5	metre	11.100
355	12.705.0355.26	355X13,6 SDR26 ISO S-12,5	metre	14.000
400	12.705.0400.26	400X15,3 SDR26 ISO S-12,5	metre	17.700
450	12.705.0450.26	450X17,2 SDR26 ISO S-12,5	metre	22.400
500	12.705.0500.26	500X19,1 SDR26 ISO S-12,5	metre	27.600
560	12.705.0560.26	560X21,4 SDR26 ISO S-12,5	metre	34.600
630	12.705.0630.26	630X24,1 SDR26 ISO S-12,5	metre	43.900
710	12.705.0710.26	710X27,2 SDR26 ISO S-12,5	metre	55.800
800	12.705.0800.26	800X30,6 SDR26 ISO S-12,5	metre	70.800
900	12.705.0900.26	900X34,4 SDR26 ISO S-12,5	metre	89.400
32	12.705.0032.17	32X1,9 SDR17,6 ISO S-8,3	metre	0.180
40	12.705.0040.17	40X2,3 SDR17,6 ISO S-8,3	metre	0.273
50	12.705.0050.17	50X2,9 SDR17,6 ISO S-8,3	metre	0.422
63	12.705.0063.17	63X3,6 SDR17,6 ISO S-8,3	metre	0.659
75	12.705.0075.17	75X4,3 SDR17,6 ISO S-8,3	metre	0.926
90	12.705.0090.17	90X5,1 SDR17,6 ISO S-8,3	metre	1.320
110	12.705.0110.17	110X6,3 SDR17,6 ISO S-8,3	metre	1.980
125	12.705.0125.17	125X7,1 SDR17,6 ISO S-8,3	metre	2.540
140	12.705.0140.17	140X8,0 SDR17,6 ISO S-8,3	metre	3.200
160	12.705.0160.17	160X9,1 SDR17,6 ISO S-8,3	metre	4.150
180	12.705.0180.17	180X10,2 SDR17,6 ISO S-8,3	metre	5.220
200	12.705.0200.17	200X11,4 SDR17,6 ISO S-8,3	metre	6.470
225	12.705.0225.17	225X12,8 SDR17,6 ISO S-8,3	metre	8.190
250	12.705.0250.17	250X14,2 SDR17,6 ISO S-8,3	metre	10.100
280	12.705.0280.17	280X15,9 SDR17,6 ISO S-8,3	metre	12.600
315	12.705.0315.17	315X17,9 SDR17,6 ISO S-8,3	metre	16.000
355	12.705.0355.17	355X20,1 SDR17,6 ISO S-8,3	metre	20.200
400	12.705.0400.17	400X22,7 SDR17,6 ISO S-8,3	metre	25.700
450	12.705.0450.17	450X25,5 SDR17,6 ISO S-8,3	metre	32.500
500	12.705.0500.17	500X28,3 SDR17,6 ISO S-8,3	metre	40.100
560	12.705.0560.17	560X31,7 SDR17,6 ISO S-8,3	metre	50.300
630	12.705.0630.17	630X35,7 SDR17,6 ISO S-8,3	metre	63.700
16	12.705.0016.11	16X1,8 SDR11 ISO S-5	metre	0.080
20	12.705.0020.11	20X1,9 SDR11 ISO S-5	metre	0.107
25	12.705.0025.11	25X2,3 SDR11 ISO S-5	metre	0.164
32	12.705.0032.11	32X2,9 SDR11 ISO S-5	metre	0.260
40	12.705.0040.11	40X3,7 SDR11 ISO S-5	metre	0.412
50	12.705.0050.11	50X4,6 SDR11 ISO S-5	metre	0.638
63	12.705.0063.11	63X5,8 SDR11 ISO S-5	metre	1.010
75	12.705.0075.11	75X6,8 SDR11 ISO S-5	metre	1.400
90	12.705.0090.11	90X8,2 SDR11 ISO S-5	metre	2.030
110	12.705.0110.11	110X10,0 SDR11 ISO S-5	metre	3.010
125	12.705.0125.11	125X11,4 SDR11 ISO S-5	metre	3.910
140	12.705.0140.11	140X12,7 SDR11 ISO S-5	metre	4.870
160	12.705.0160.11	160X14,6 SDR11 ISO S-5	metre	6.390
180	12.705.0180.11	180X16,4 SDR11 ISO S-5	metre	8.070
200	12.705.0200.11	200X18,2 SDR11 ISO S-5	metre	9.950
225	12.705.0225.11	225X20,5 SDR11 ISO S-5	metre	12.590
250	12.705.0250.11	250X22,7 SDR11 ISO S-5	metre	15.480
280	12.705.0280.11	280X25,4 SDR11 ISO S-5	metre	19.400
315	12.705.0315.11	315X28,6 SDR11 ISO S-5	metre	24.550
12	12.705.0012.07	12X1,8 SDR7,4 ISO S-3,2	metre	0.057
